Complies with the IEEE802.3af/at standard and automatically detects and identifies PD devices that comply with the IEEE 802.3af/at standard. It can supply power to a single port up to 30W.
8 Ethernet Port and 2 Uplink Ethernet Port allows to connect with different devices, one button to achieve intelligent run.
Plug and play for very simple installation, no configuration required.
Supports MDI/MDIX auto-flip and auto-negotiation on each port.
Supports IEEE 802.3x full-duplex flow control and Backpressure half-duplex flow control.
OverviewPOE Port: 1-8 Port Support IEEE 802.3af/at(15.4W/30W) Network Power Supply
SEP Port: Non Support
PoE Switch Output Power: 15.4W/30W IEEE802.3af/at
PoE Switch Wire Core: 1/2+, 3/6-
Port Description: 8 Ethernet Port, 2 Uplink Ethernet Port
PoE Switch Connection Standard: IEEE802.3af/IEEE802.3at
PoE Switch Transmission Distance: ≤250m / 820.2ft
PoE Switch Type: End Bridging Method
Network Standard: IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3af/at
Network Medium: 5 Category and above unshielded twisted pair
Network Signal Distance: Transfer ≤250m / 820.2ft
Gbps: 2.0Gbps
Forwarding Way: Storage Forwarding
Forwarding Rate: 10Base-T:14880PPS/port, 100Base-TX:148800PPS/port
For MAC Address: 2KMAC
Port Function: Power supply priority mechanism, fast and forwarding, For MAC automatic learning and aging, IEEE 802.3X full duplex flow control and Backpressure half duplex flow control
Indicator: Each port has one Link/Act and PoE Switch indicator and each equipment has one Power indicator
Operating Temperature: -20℃~40℃
Storage Temperature: —40℃~70℃
Work Humidity: 10%-90%RH(no condensation)
Storage Humidity: 5%-90%RH(no condensation)
Power Supply: Power Adapter(AC100-240V)
Overall Power Consumption: ≤ 10W
Specifications
Colour Name
Black
Connection Type
Ethernet Cable
Product Length
7.9 in
Product Height
1.7 in
Product Width
4.6 in
Set Includes
1 x POE Switch
1 x Manual
1 x Power Adapter
Features
Business, Travel, Personal
Model Number
895-LU
Model Name
895-LU
