Maximum Measuring Distance | 100 m |
Measurement Accuracy (mm / m) | 0.2 mm |
Tripod Connection | Yes |
Laser rangefinder
This professional outdoor laser rangefinder features a digital camera target display with zoom function to accurately measure distances up to 100 m. The camera image and measurements are easily viewed on the large, high-contrast, 2.8" IPS color display, which can be rotated for portrait or landscape view. Measurement results can be transferred via Bluetooth to the Bosch MeasureOn app for convenient documentation. This laser rangefinder is IP54 dust and splash proof Protection is the ideal solution for harsh conditions thanks to its scratch-resistant screen glass.
Architects, site supervisors and electricians can benefit from the outdoor capability, easy readability and useful documentation of this rugged laser rangefinder.
The GLM 100-25 C Professional features a user-friendly HMI interface with a click wheel to access all features. A handy help option displays detailed images of each measurement function for easy understanding.
Additional data | |
---|---|
Data transfer | Bluetooth™ 4.2 Low Energy |
laser color | Red |
Measuring time, type. | < 0,5 s |
laser diode | 650nm,< 1 mW |
Measuring area* | 0.08 – 100.00m |
laser class | 2nd |
Measuring accuracy, typ.* | ± 1.5 mmᵈ |
Measuring range, slope measurement | 0-360° (4 x 90°) |
Measuring accuracy (typical)* | ± 0.2°ᶜ |
Measuring time max. | 4 sec |
current supply | 3 x 1.5V LR6 (AA) |
Current cut-off automatic | 5 min |
Weight, approx.** | 0.23kg |
units of measurement | m/cm/mm/ft/inch/ft inch |
Number of memory values | 50 |
Protection against dust and spray water | IP 54 |
fixed tooth | 1/4" |
digital viewfinder | integrated |
Measuring range, max. | 100 m |
