Highlights- Experience Gaming Like Never Before On The Legion 5I Gaming Laptop Powered By 10Th Gen Intel Core H-Series Processors
- Legion 5I Has You Covered With Options That Satisfy Both Needs On A 15.6″ Fhd Ips (1920 X 1080) Display
- Keep all your conversations private with the help of an easy-to-activate mute button
OverviewLenovo Legion 5 15IMH05H
Part Number : 81Y6009MAX
PERFORMANCE
Processor: Intel Core i7-10750H (6C / 12T, 2.6 / 5.0GHz, 12MB)
Graphics: NVIDIA GeForce RTX 2060 6GB GDDR6
Chipset: Intel HM470
Memory: 2x 8GB SO-DIMM DDR4-2933
Memory Slots: Two DDR4 SO-DIMM slots, dual-channel capable
Max Memory: Up to 32GB DDR4-2933 offering
Storage: 256GB SSD M.2 2280 PCIe 3.0x4 NVMe + 1TB HDD 5400rpm 2.5"
Storage Support: Up to two drives, 1x 2.5" HDD + 1x M.2 2242 SSD, 1x 2.5" HDD + 1x M.2 2280 SSD, or 2x M.2 2280 SSD
• 2.5" HDD up to 2TB
• M.2 2242 SSD up to 512GB
• M.2 2280 SSD up to 1TB
Card Reader: None
Optical: None
Audio Chip: High Definition (HD) Audio, Realtek ALC3287 codec
Speakers: Stereo speakers, 2W x2, Dolby Atmos for gaming, HARMAN-branded
Camera: 720p with Privacy Shutter
Microphone: 2x, Array
Battery: Integrated 60Wh
Max Battery Life: MobileMark 2018: 5.9 hr (60Wh)
Power Adapter: 230W Slim Tip
DESIGN
Display: 15.6" FHD (1920x1080) IPS 300nits Anti-glare, 144Hz, 100% sRGB, Dolby Vision
Touchscreen: None
Keyboard: 4-Zone RGB LED backlit, Arabic
Case Color: Phantom Black
Surface Treatment: Painting
Case Material: PC + ABS (Top), PC + ABS (Bottom)
Dimensions (WxDxH): 363.06 x 259.61 x 23.57-26.1 mm (14.3 x 10.22 x 0.93-1.03 inches)
Weight: 2.46 kg (5.42 lbs)
SOFTWARE
Operating System: FreeDOS
Bundled Software: None
CONNECTIVITY
Ethernet: 100/1000M
WLAN + Bluetooth: 11ax, 2x2 + BT5.0
Standard Ports:
-3x USB 3.2 Gen 1
-1x USB 3.2 Gen 1 (Always On)
-1x USB-C 3.2 Gen 1 (support data transfer and DisplayPort 1.2)
-1x HDMI 2.0
-1x Ethernet (RJ-45)
-1x headphone / microphone combo jack (3.5mm)
-1x power connector
SECURITY & PRIVACY
Security Chip: Firmware TPM 2.0
Fingerprint Reader: None
Physical Locks: Kensington Security Slot
Other Security: Camera privacy shutter
Bundled Service: None
ACCESSORIES
Bundled Accessories: None
CERTIFICATIONS
Green Certifications:
-ErP Lot 3
-RoHS
