الميزات الأساسية- 3 1/2 digits LCD display with white backlight.
- Designed for measuring resistance, capacitance and inductance, also can be used to test transistor.
- Overload protection, over range and low battery indication.
- Powered by a 9V battery(not included), low consumption.
- Compact size, light weight, convenient to carry.
نظرة عامةThis digital resistance capacitance inductance meter with stable performance and accurate results is suitable for fieldwork, laboratory, factory use. With compact size, light weight, it is convenient to carry.
Features:
3 1/2 digits LCD display with white backlight.
Designed for measuring resistance, capacitance and inductance, also can be used to test transistor.
Overload protection, over range and low battery indication.
Powered by a 9V battery(not included), low consumption.
Compact size, light weight, convenient to carry.
Specifications:
Display: 3 1/2 Digits LCD
Resistance Range: 20Ω/200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ/200MΩ/2000MΩ
Resistance Resolution: 0.01Ω/0.1Ω/1Ω/10Ω/100Ω/1kΩ/10kΩ/100kΩ/1MΩ
Capacitance Range: 2000pF/20nF/200nF/2μF/20μF/200μF
Capacitance Resolution: 1pF/10pF/100pF/1nF/10nF/0.1μF
Inductance Range: 20mH/200mH/2H/20H
Inductance Resolution: 0.01mH/0.1mH/1mH/10mH
Working Temperature: 0~40°C
Working Humidity: <=75%RH
Power Supply: 1 * 9V Battery(not included)
Item Size: 14 * 7 * 3cm / 5.5 * 2.8 * 1.2in
Item Weight: 154g / 5.4oz
Package Size: 18 * 10 * 4.5cm / 7.1 * 3.9 * 1.8in
Package Weight: 245g / 8.7oz
Package List:
1 * Meter (battery not included)
1 * Pair of Test Probes
1 * User Manual
