Grundfos - Unilift AP50B.50.08.A1.V

OverviewSpecifications Product name UNILIFT AP50B.50.08.A1V Product No 96468354 EAN number 5700394943666 Technical Maximum flow 6.67 l/s Maximum head 11 m Type of impeller VORTEX Max. Particle 50 mm Rated speed 2790 rpm Materials Pump housing Stainless steel EN 1.4301 AISI 304 Impeller Stainless steel EN 1.4301 AISI 304 Installation Range of ambient temperature 0 .. 40 °C Type of connection Rp Size of connection 2 inch Maximum installation depth 7 m Inst dry/wet S Auto-coupling Y Liquid Liquid temperature range 0 .. 40 °C Density 998.2 kg/m³ Electrical data Power input P1 1.2 kW Motor type 1-phase PSC Rated power - P2 0.74 kW Mains frequency 50 Hz Rated voltage [V] 1 x 230 V Rated current 5.37 A Cos phi - power factor 0.97 Rated speed 2790 rpm Capacitor size - run 16 µF/400 V Enclosure class (IEC 34-5) IP68 Insulation class (IEC 85) F Built-in motor protection CONTACT Thermal protec internal Length of power cable 10 m Type of cable plug SCHUKO Controls Level switch float switch Others Net weight 11.6 kg Gross weight 12.9 kg Danish VVS No. 391272322 Swedish RSK No. 5886036 Quotation UNILIFT AP50B.50.08.A1V Submersible effluent pump Vertical single-stage stainless steel submersible pump with integrated submersible 1-phase motor. The pump is fitted with ring stand and carrying handle and is supplied with a 10 m mains cable and a level switch for automatic start and stop. The impeller is a VORTEX impeller for surface water, groundwater, wastewater and similar. The pump has a double shaft seal and an intermediate oil chamber pre-filled with non-toxic special oil. The motor is insulation class F with thermal overload protection and has long-life deep-groove greased-for-life ball bearings. ready for installation either free-standing or on an auto-coupling system.
