Features:
High Performance: 4 DDR4 dual-channel, up to 128GB, greatly improving the motherboard's performance, equipped with LGA2011-3 V3/V4 intel Xeon CPU, achieving a high-performance cost-effective solution.
Fast and Stable: Full-speed M.2_NVMEM, M.2_NGFF interface, M.2 supports 32GB/s data transfer speed, stable and fast.
High-speed Data Transfer: USB 3.0 interface, plug and play, instantly feel 10 times faster data transfer speed than USB2.0.
Gigabit Network: RTL8111H 1Gbps, using gigabit network, dedicated to heavy load fast network.
High Compatibility: All solid capacitors/SATA3.0 interface, high compatibility, fast read and write speed.
Stable and Durable: 8-layer printed circuit board, more stable and durable, aluminum heat sink, enhanced stability, better performance.
Specification:
Form factor: M-ATX
Dimension: 240MM X 205MM
CPU Socket: LGA2011-3 V3 / 4 intel Xeon CPU
of RAM Slots: 4*DDR4 slots, support up to 128GB ( ECC )
Audio: Realtek ALC897 HD 7.1
Network: Gigabit Ethernet
SATA Port: 3*SATA3.0, 2*SATA2.0
M.2 Slots: M_Key / Type 2280 support NVME PCLE3.0 x4
M_Key / Type 2280 support SATA3.0 protocol SSD
PCI-E Slots: 1*PCI-E 3.0 X16, 1*PCI-E 3.0 X4
USB Interface: 4*USB3.0, 6*USB2.0( Front 2*USB3.0, 4*USB2.0 )
PSU Connector: ATX 24PIN + AUX12V_8PIN
Other: F_PANEL, F_AUDIO, F_COM, F_SPK, 4*PIN CPU_FAN, 3PIN SYS_FAN, PS/2 Mouse, PS/2 Keyboard
Package size: 290*240*60mm
Package weight: 800g
Package list:
1*Motherboard
1*SATA Cable
1*Motherboard Baffle
