T-1300 8-Channel Intelligent Power Sequence Controller Universal Time Sequencer Controller 8 Controllable Outputs 1 Auxiliary Output With Lcd Touchscreen Supply Voltage Ac100-240V

OverviewFeatures: Equipped with 2.2 inches and pixel of 176*220 LCD colorful touchable screen. The screen shows the current voltage, date, time, state of each channel (on/off). Fashion design with brushed aluminum panel. 8 channels output, delay time of booting up and shutting down of each channel can be set (range: 0~999sec). A clock chip is build-in for users to set the date and time to boot up/shut down each channel. Users can set the value of low-voltage/overvoltage protection. Users can operate the device by cascading, external controlling or central controlling via RS232 and RS485 ports. Total rated output current: 40A. Individual channel rated output current: 20A. Suitable for stages, home theatre, KTV rooms and conference rooms, etc. Specifications: Brand: Flannge Model: T-1300 Supply Voltage: AC100-240V / 50~60Hz Individual Channel Rated Output Current: 20A Total Rated Output Current: 40A Interval Time of Each Sequence Step: 1~999s USB Power Supply: DC 5V/500mA Power Output Sockets: 8 controllable outputs, 1 auxiliary output Item Size: 48.2 * 22.3 * 4.5cm / 19 * 8.8 * 1.8inch Item Weight: 3165g / 111.6oz Package Size: 54 * 32.7 * 10.8cm / 21.3 * 12.9 * 4.3inch Package Weight: 3712g / 130.9oz Package List: 1 * Flannge T-1300 Intelligent Power Sequence Controller 1 * User Manual (English) Note: Power cable of device IS NOT EQUIPPED WITH PLUG. User can chooes their needed plug according to practical situation, or connect the power cable directly to air switch or knife switch.
