USB To SATA IDE Serial Parallel Port Cable Line for 2.5/3.0 inch Hard Disk Black

OverviewUSB To SATA IDE Serial Parallel Port Cable for 2.5/3.0 inch Hard Disk With Power Adapter

Features:
1. High speed USB2.0 transmission speed up to 480Mb/s, down compatible with FULL-SPEED USB, support hot plug, plug and play.
2. It can be used in notebook 2.5 inch IDE hard disk, desktop 3.5 inch IDE hard disk, CD-ROM drive, recorder, Canbo, SATA hard disk drive.
3. Small size, light weight, easy to carry, installation is extremely simple.
4. Offline data protection, safe and reliable.
5. The special switching power supply is stable and reliable under various voltage of 90V to 264V.
6. Hardware requirements: with USB interface.
7. Operating system: applicable to Win 98, Win Me, Win 2000, Win XP, win7, win8 and so on

Specifications:
Interface type: IDE/SATA
Network engineering: hard disk
Home improvement project: hard disk drive line
Suitable equipment: personal computer
Wire material: Copper
Process: ABS assembly
Color: Black
Interface type: USB 2 high speed interface, down compatible with USB 1.1
Transmission speed: up to 480Mbps
Connectable storage devices: SATA interface, 44 pin IDE interface, 80 pin IDE line interface (down compatible with 40 pin IDE interface)
Power supply type: 100-240V equipped with 2A power adapter power supply

Supported hard disk types:
1. SATA-1.5G/s and SATA 2-3.0G/s hard disk.
2. 2.5" 44 pin IDE laptop hard disk.
3. 3.5'' 40 pin or 80 pin IDE desktop hard disk
4. 5.25" IDE interface CDROM//DVDROM

USB 2.0 high speed 480Mbps
SATA 1.5Gbps
SATA 2 3.0Gbps
ATA/ATAPI PIO mode 0 to 4
ATA/ATAPI Ultra DMA of transfer rate 16.7, 25, 33, 48, 66, 100, 133, and 150MB/s
ATA/ATAPI LBA48 48 bit addressing (more than 2TB--2000GB hard disk addressing capability)
Power input: AC 90V ~ 264V 47 ~ 63Hz
Transmission interface: USB2.0 (can be compatible with USB 1.1 downward)
Storage medium: 2.5, 3.5 inch hard disk, standard CD-ROM (DVD-ROM), CD-RW, COMBO
Transmission speed: maximum peak 480Mb/s (Max), support high speed recorder

Operation Manual:
1. Confirm the equipment has been set as Master (main disk) touch type.
2. Connect the SATA/IDE connector to the device.
3. Connect the equipment to the power supply.
4. In the normal operation of the computer, and finally connected to the USB interface.

Note:
Please allow 1-3 cm differs due to manual measurement.
Due to the different display and different light, the picture may not show the actual color of the item. Thanks for your understanding.


Package Content:
1 x Power Adapter
1 x Power Cable
1 x SATA Data Cable
1 x Parallel Port Cable
1 x Serial Port Cable
