315MHz Wireless Remote Control Key Fob 4 Buttons Clone Switch Portable Cloning Copy 315MHz Electric Gate Garage Door Opener Control Duplicator

OverviewNote:1. The essential condition for the selection of the remote control, the copyed remote control operates normal, chip is compatible and frequency is correct.2. Before buying, please make sure the copyed remote control operating frequency or choose & buy the frequency adjustable type remote control.3. Before buying, please confirm whether your remote control can be copyed or not.4. The remote control can copy the fixed codes and learning codes. It can't copy car remote control, two-way remote control and rolling code remote control (Rolling code chips start with HCS commonly, such as HCS200, HCS201, HCS300, HCS301, etc)


Features:
* Wireless remote control duplicator is widely used in Vehicle central locking systems, Garage doors, Electronic gates, Electrical appliances, Home automation, lights, Car sunroofs, Car/Motorbike alarms, etc.
* Ultra-small error of copying data code and copy oscillation resistance. High accuracy of copying and high effective of copying, easy to install and use. Privacy is strong. Each key password alone save.
* 315MHz, transmit distance is 50-100m(Open space), bringing you new experience of remote control and much convenience in your daily life.
* Stable signal can pass through walls, floors, doors or windows.
* It includes the Remote Control only, other accessories in the picture are not included!

Program Instructions:
1. Delete the existing code of our remote duplicator
1) Click and Hold A and B buttons together - Led will flash 3 times.
2) Keep holding A button and release B button.
3) Keep holding A button and push B button 3 times, Led will start flashing Non-stop.
Now press any key on the remote control, LED lights are not bright, so delete code success; if you press the button LED lamp is lit, indicating that the code is not deleted !

2. Clone your remote
1) Put both remotes Into back to Back position. Make sure they have direct contact.
2) Click and hold 1 button on your remote and 1 button on your clone remote. Keep holding until led will make 2 blinks.
3) Blinks then goes into Steady and you have successfully cloned. (the left keys follow the same above operation)
If for some reason the clone does not go further then 2 blinks, it means the signal does not go through, please shift the remote slowly up and down until you get the point where it will go through.


Specifications:
Operating Voltage: DC12V
Operating Current: 12mA
Button: 4 Buttons
Battery: button battery (included)
Wireless Communication: RF
RF Frequency: 315MHz
Encoding Type: Self Copy
Modulation System: ASK (Amplitude Modulation)
Transmission Distance: 50-100m(Open space)
Material: ABS
Item Size: 9*6*1.5cm
Package Size: Approx. 9*6*1.5cm
Package Weight: Approx. 21g


Package List:
1* Remote Controller (with battery)
