AS63A Digital Vibration Meter with LCD Screen Vibration Analyzer Tester AC Output Acceleration / Velocity / Displacement Measurement

OverviewSpecifications: Brand: SMART SENSOR Model: AS63A Color: Grey Shell Material: ABS Vibration Pickup: Piezoelectric ceramic accelerometer ( shear-type ) Measurement Range Of Acceleration: 0.1-199.9m/s² peak Measurement Range Of Velocity: 0.1-199.9mm/s rms Measurement Range Of Displacement: 0.001-1.999mm p-p ( Velocity and displacement range is limited by acceleration 199.9m/s² ) Measurement Accuracy: ±10% + 2 digits Measurement Frequency Range Of Acceleration: 10Hz-1KHz (LO), 1KHz-15KHz (HI) Measurement Frequency Range Of Velocity: 10Hz-1KHz (LO) Measurement Frequency Range Of Displacement: 10Hz-1KHz (LO) Displays Update Cycle: 1 seconds LCD Display: 3 1/2 digits display Single Output: AC output 2V peak (display full scale), load impedance 10KΩ or more earphones can be connected Power Supply: 1.5V AAA battery ( not included ) Static Current: ≤20uA Operating Current: ≤25mA Auto Power-off Function: Turns off automatically after 60 seconds LCD Backlight Function: 7 seconds Operating Temperature Range: 0~40℃ Operating Humidity Range: 30~90% RH Low Battery Indication: 2.2V ± 0.2V Storage Case Size: 23.5*18*5cm / 9.25*7.09*1.97in  Vibration Meter Size ( with Short Probe ): 6.7*3*18.3cm / 2.64*1.18*7.20in  Vibration Meter Weight: 147g / 5.19oz Packing Size: 25.5*21*5.8cm / 10.03*8.27*2.28in Gross Weight: 610g / 21.52oz
