Product Overview

Specifications: Name: Heating Platform  Material: plastics+metal Model: MPH50-BS50, MPH50-AL50 (optional) Heating plate material:  AL50: aluminum alloy BS50: copper body with a ceramic coating Display: 160*80 color LCD Temperature ranges: 100-350℃ Temperature stability: ±3% Power interface: USB Type-C and DC5525 Input voltage: 19-24VDC, 20 VPD Max power: DC5525 150W, PD 100W Heating size: 50 * 50 * 29mm / 1.97 * 1.97 * 1.14in Item size: 71.5 * 55.5 * 22.5mm / 2.81 * 2.19 * 0.89in Item weight: MPH50-AL50: 138g / 4.88ounce MPH50-BS50: 165g / 5.82ounce Package size: 108 * 108 * 71mm / 4.25 * 4.25 * 2.80in Package weight: MPH50-AL50: 302g / 10.65ounce MPH50-BS50: 328g / 11.57ounce

Highlights

  • Scientific Design: Lower height design not easy to dump, smoother desoldering, more flexible to use. 50*50mm enlarged heating area, applicable to more scenes.
  • Split Design: The controlling end and the heating end can be separated, directly plugged and replaced, more flexible and convenient to replace.
  • Built-in Cooling Fan: Innovative use of the principle of airconduction, combined with fan blowing and airconduction cooling, fan automatic speed regulation, with fast cooling speed and nice cooling result.
  • LCD Color Screen: Equipped with LCD color display, 160*80 resolution, display upgrade, new operation interaction, clear interface, rich display, keyfront, and convenient operation.
  • Segmented Heating: The new "reflow soldering" heating curve design, can set the heating temperature and time in segments, simulating the function of the reflow oven, intelligent temperature control, accurate heating, and reflow soldering.

Specifications

Product Weight0.33 KG
Country of OriginChina
Product Height7.1 cm
What's In The Box1 * Control End 1 * Heating Plate 1 * PD Cable  1 * Guideline
Model NameMHP50-BS50
Colour NameMulticolour
Product Length10.8 cm
Product Width10.8 cm
Model NumberMHP50-BS50
Number of pieces1
