Highlights- 8 Output Controls: Main heating, auxiliary heating, illumination, humidity control, circulation fan, right side eggs turner, left side eggs turner, exhaust fan.
- Incubation Days Counting: Records the controller started working days, maximum 99 days can be recorded
- Eggs Turning Control: Adjustable from 1 minute to 999 minutes, adjustable eggs turning time from 0 to 999 seconds, adjustable eggs turning time from 0 to 999 times. Eggs turning function, eggs counting function can be switched off.
- Exhaust Control: Exhaust period adjustable from 1~999 minutes, exhaust time adjustable from 0-999 seconds, with off timer function for air change.
- Illumination Control: Adjustable from 1 to 999 minutes, adjustable illumination time from 1 to 999 seconds, with off timer illumination function.
OverviewSpecifications:
Name: Eggs Incubator Controller
Main material: plastics
Model: ZL-SHr05A, ZL-SHr05B (optional)
Voltage: 100-240Vac, 50/60Hz.
Temperature setting ranges: 0-75℃/32-167℉
Humidity setting ranges: 0-80%(ZL-SHr05A), 0-99% (ZL-SHr05B), depending on your selection
Measuring accuracy: Humidity 3%@25℃, Temperature 1%@25℃.
Output load: main-heater ≤ 1500W, aux-heater ≤ 1500W, lamp ≤ 100W, others ≤ 1A/250VAC.
Installation drilling size: 151.5 * 76.5mm / 5.96 * 3.01in
Item size: 160 * 80 * 95mm / 6.30 * 3.15 * 3.74in
Item weight: 491g / 1.08lb
Package size: 175 * 135 * 100mm / 6.89 * 5.31 * 3.94in
Package weight: 555g / 1.22lb
