Highlights- Rated Current: 63A
- Voltage: 400V
- No. of Poles: 5
- Clock Hour Position: 6
- Degree of Protection: IP44
- Frequency: 50/60Hz
- Cable Entry: Gland Nut
- Connection System: Screwed Terminal
- Contact Material: Brass
- Housing Material: PA6
OverviewThe PCE Red Color 5 Poles 6h 32A 400V Wall Mounted Socket Power Twist IP44 is a high-quality wall socket designed for industrial use. It features a rated current of 63A and a voltage of 400V. The socket has 5 poles and a clock hour position of 6. It offers a degree of protection of IP44 and operates at a frequency of 50/60Hz. The cable entry is through a gland nut, and the connection system is a screwed terminal. The contacts are made of brass, and the housing material is PA6. The socket is designed for inner lying mounting and can withstand ambient temperatures ranging from -25 to 40°C, with a temperature resistance of -25 to 80°C. The product is manufactured by PCE and originates from Austria.
