Transistor Tester Diode Capacitance ESR Meter Signal Generator MOS Triode

Highlights

• Transistor Tester can be powered from 6.8V – 12V DC. This can be achieve by a 9V layer-built battery. Two
• 7V Lithium-ion battery in series. Or AC adapter. When power on , the current is about 30mA at DC 9V.
• Transistor Tester is control by a rotary pulse encoder with switch, or short by
• when Transistor Tester is powered. a Short time press of the RPEWS will switch on the Transistor Tester, and start a Test.
• Transistor Tester will waiting for user input at the end of a test.
• Transistor Tester have three Test point(TP1,TP2,TP3), within the Test socket, the three is allocation as follow
